| General Specifications | |
| Model No. | TI-25T |
| Plastic Type | Thermoplastic |
| Automation Grade | Semi Automatic |
| Clamping Way | Hydraulic |
| Machine Color | Blue |
| Brand | Techlon India |
| Injection Unit | |
| Plasticizing Way | Screw Type |
| Screw Diameter | 30 / 32 / 35 mm |
| Screw Speed | r.p.m |
| Screw Stroke | mm |
| Nozzle Stroke | mm |
| Nozzle Contact Force | tf |
| Injection Pressure | 1171 / 996 / 820 Kg/cm² |
| Shot Weight | g |
| Injection Capacity | cm3 |
| Injection Rate | cc/s |
| Clamping Unit | |
| Clamping Force | 25 Ton |
| Clamping Stroke | mm |
| Distance B/w Tie Bars | 410 × 250 mm |
| Platen Size | 580 × 430 mm |
| Min. Mold Height | 70 mm |
| Max. Mold Space | mm |
| Electrical & Control System | |
| Control System | PLC Controlled |
| Power Supply | 415V, 3 Phase, 50Hz |
| Motor Power | 5 Kw |
| Machine Physical Details | |
| Machine Dimension | 1700 × 1200 × 3000 mm |
| Machine Weight | 2400 kg |
