| General Specifications | |
| Model No. | TI-15T |
| Plastic Type | Thermoplastic |
| Automation Grade | Semi Automatic |
| Clamping Way | Hydraulic |
| Machine Color | Blue |
| Brand | Techlon India |
| Injection Unit | |
| Plasticizing Way | Screw Type |
| Screw Diameter | 28 / 30 / 32 mm |
| Screw Speed | 0-150 r.p.m |
| Screw Stroke | 90 mm |
| Nozzle Stroke | 120 mm |
| Nozzle Contact Force | 2.4 tf |
| Injection Pressure | 1500 Kg/cm² |
| Shot Weight | 35-50 g |
| Injection Capacity | 47 cm3 |
| Injection Rate | 39 cc/s |
| Clamping Unit | |
| Clamping Force | 15 Ton |
| Clamping Stroke | 200 mm |
| Distance B/w Tie Bars | 320 × 220 mm |
| Platen Size | 450 × 350 mm |
| Min. Mold Height | 70 mm |
| Max. Mold Space | 240 mm |
| Electrical & Control System | |
| Control System | PLC Controlled |
| Power Supply | 415V, 3 Phase, 50Hz |
| Motor Power | 2.2 Kw |
| Machine Physical Details | |
| Machine Dimension | 1200 × 900 × 2200 mm |
| Machine Weight | 1200 kg |
